Dyeing And Knitting Electric Heating Vacuum singeing textile

   Open Width Knitting Fabric Singeing Machine Horizontal Nonwoven Fabric Textile Singeing Machine

 Use in corduroy, denim, Khaki Drills, canvas and other singeing. Remove the fluff on the surface of the fabric and improve the finish.

      Product details

    The main features of the equipment

     1. SLXX / 270 energy drum drum singeing machine to industrial power for the kinetic energy, using a new type of energy efficient materials silicon carbide rod for the heating heat source, iron nickel chromium alloy cylinder for the heat burner. Fire cylinder diameter 270mm, the cylinder built-in 4 diameter 40mm specifications of the straight type silicon carbon rods. And the cold end of the cylinder and the heating zone has been protected.

      2. The original fuel singeing machine fire for the naked singeing, the singeing work surface is only 20% of the cylinder, a considerable part of the calorific value will be lost in the singeing. The equipment in the cylinder under the burning of the insulation box, the drum 70% of the non-working surface to be insulation, resulting in the cylinder temperature in the work of long-term to maintain the set process temperature, while reducing the silicon carbide Of the frequent thermostat, the energy-saving effect is obvious.

      3. The electrical system of the device is fully designed according to the principle of singeing and the characteristics of silicon carbon rod, the whole intelligent control, in the set temperature of 800 to 1000 degrees interval, silicon carbide actual power consumption of less than 70%, and thus larger Saving power consumption. Unique circuit design to ensure that the equipment is stable, reliable operation, and easy to control, safe.

      Second, the equipment of the main technical indicators:

      Model and specifications SLXX / 270 Effective work Width 200--1900mm Transmission speed 20 ~ 110m / min Cylindrical specifications ∮ 270 × 2530 silicon carbide rod combination 2 × 2 × ∮45 Flash surface temperature 900 ~ 1000 ℃ installed capacity 180KW

      Third, the comparison of similar equipment

       This equipment is compared with the conventional fuel cylinder singeing machine, gas burner singeing machine with less energy consumption, high surface temperature, small temperature difference singular grade, no environmental pollution, good equipment stability and so on. More conventional singeing machine, the same variety of singeing can save production costs as much as three-fifths.
