Desizing Textile Singeing Machine Process Stainless Steel
Technical Parameter
1. Sweden imported high temperature and high nickel stainless steel - 25123
2. Quality requirements Technical standards: (Ni:25 Si:2 )
3. This product is a new material for singeing machine equipment. Features; uniform temperature, burn out the cloth effect is good, long service life.
Use in corduroy, denim, Khaki Drills, canvas and other singeing. Remove the fluff on the surface of the fabric and improve the finish.
Name | Textile Singeing Machine |
Model and specifications | SLXX / 270 |
Effective work Width | 200--1900mm |
Transmission speed | 20 ~ 110m / min |
Cylindrical specifications | ∮ 270 × 2530 |
silicon carbide rod combination | 2 × 2 × ∮45 F |
lash surface temperature | 900 ~ 1000 ℃ |
installed capacity | 180KW |
Product details
The main features of the equipment
1. SLXX / 270 energy drum drum singeing machine to industrial power for the kinetic energy, using a new type of energy efficient materials silicon carbide rod for the heating heat source, iron nickel chromium alloy cylinder for the heat burner. Fire cylinder diameter 270mm, the cylinder built-in 4 diameter 40mm specifications of the straight type silicon carbon rods. And the cold end of the cylinder and the heating zone has been protected.
2. The original fuel singeing machine fire for the naked singeing, the singeing work surface is only 20% of the cylinder, a considerable part of the calorific value will be lost in the singeing. The equipment in the cylinder under the burning of the insulation box, the drum 70% of the non-working surface to be insulation, resulting in the cylinder temperature in the work of long-term to maintain the set process temperature, while reducing the silicon carbide Of the frequent thermostat, the energy-saving effect is obvious.
3. The electrical system of the device is fully designed according to the principle of singeing and the characteristics of silicon carbon rod, the whole intelligent control, in the set temperature of 800 to 1000 degrees interval, silicon carbide actual power consumption of less than 70%, and thus larger Saving power consumption. Unique circuit design to ensure that the equipment is stable, reliable operation, and easy to control, safe.
Second, the equipment of the main technical indicators:
Model and specifications SLXX / 270 Effective work Width 200--1900mm Transmission speed 20 ~ 110m / min Cylindrical specifications ∮ 270 × 2530 silicon carbide rod combination 2 × 2 × ∮45 Flash surface temperature 900 ~ 1000 ℃ installed capacity 180KW
Third, the comparison of similar equipment
This equipment is compared with the conventional fuel cylinder singeing machine, gas burner singeing machine with less energy consumption, high surface temperature, small temperature difference singular grade, no environmental pollution, good equipment stability and so on. More conventional singeing machine, the same variety of singeing can save production costs as much as three-fifths.
Product Catalogue
Machine Type | Cloth Guide Speed | Motor Power | Machine Size |
Corduroy Cutting Machine | 12m /min | 9kw | 250cm * 235cm * 220cm |
Textile Singeing Machine | 20 ~ 110m / min | 180KW | 250cm * 235cm * 225cm |
Textile Dryer Machine | 10 ~ 50m / Min | 10 ~ 22kw | 15000 × 3400 × 3600 (Mm) |
Fabric Inspection Machine | 1400rpm/min | 7KW | 235cm*350cm*230cm(72") |
Fabric Inspection Machine | 0-150m/min | 7KW | 250cm * 235cm * 210cm |
Fabric Inspection And Rolling Machine | ≤100m/min | 1.5kw | 2235(L)*2600~3600(W)*2000(H) |
Fabric Brushing Machine | 8~22m/min | 14.5-25kw | 250cm * 235cm * 220cm |
Fabric Folding Machine | 80y/Min | / | 2450*2820*1550 |
FAQ
Q1. Are you trading company or manufacturer?
We are factory. The company is located in Lijia Town, Wujin District, Changzhou City, Jiangsu Province, China.
Q2. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
Q3. Why choose us?
1.Professional Advice and Product Knowledge
2.Prompt Reply for Quotion and other questions
3.Specific Guarantee and Best after service
Q4. Do you inspect the finished products?
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
Q5. What products do you have?
Corduroy Cutting Machine, Textile Singeing Machine,Textile Dryer Machine,Fabric Inspection Machine,Fabric Inspection And Rolling Machine,Fabric Brushing Machine,Fabric Folding Machine, etc.
Q6. What is the order process?
Inquiry - Communication - Quotation - Order confirmation - Payment - Production - Test and commissioning - Packaging - Delivery - Customer reception - After-sales service.
Q7. How about your warranty?
Generally,our warranty is one years. Within the warranty period, we can offer technique support.
Q8. What mode of transportation do you use?
We generally use the mode of sea transportation. If you have any special requirements, you can contact us for discussion.
Q9. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
Q10. Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.
