Corduroy Cutting Machine
>
|
| Place of Origin | jiangsu,China |
| Brand Name | Smoothly |
| Certification | ISO9001 |
| Model Number | 200 210 220 280 300 320 340 |
China High Quality Corduroy Cutting Machine Long Service Life
Model: SL180 (200) A Type or B Type
Application: To cut the weft float of corduroy greige cloth at lateral direction.
Nominal Full Width: SL180～1800mm SL200～2000mm
Characteristic: A Type—Electromagnetic clutch, convenient operation, stable production quality and convenient maintenance.
B Type—Variable-frequency control, 2-12m/min stepless speed regulation, instant locking, less and small holing and energy conservation.
Installed Power: 6～7KW
Overall Dimensions: (L*W*H) 2,150 (2,350)*2,250*2,700 (mm)
Main specifications
| Name | Corduroy Cutting Machine |
| Main Specifications | 210b 200b 180b 180b-350m(Wide New Product) |
| Machinable Fabric Door Width | 2000mm 900m 1700mm To 3500mm |
| Fabric Guide Speed | 12min/M |
| Knife Shaft Speed | 1440rpm/1440rpm/1440rpm |
| Knife Shaft Diameter | 114m |
| The Motor Power | 9kw |
| Machine Exterior (Length*Width*Height) | 2500*3500*2400 |
| Characteristic |
Type B -frequency conversion control ,2~12m/min stepless speed regulation,instantaneous stop,puncture holes and small,save energy. |
Welcome
Come to exchange guidance
Note:the machine is mainly used for wick flannelette
Application :
1.Suitable for jeans, denim and corduroy engraving.
2.Applicable to jeans, apparel and household products industry.
It is also called jeans laser engraving machine, denim laser engraving machine, jeans engraving machine, laser cut denim, laser cut jeans.
Technical Data:
| Laser Generator and Optic parameters | |||
| Laser Type | USA Co2 RF metal tube | Laser Power | 500W |
| Laser Wavelength | 10.6 micro meters | Galvo Scanning effective area | 1100mm*1100mm |
| Galvo process speed | 0-20000mm/s (defined as the process material and requirement) |
||
| Software system | |||
| Control software | Perfect Laser's original software | ||
| Software Format | BMP, AI, DST, DXF, PLT, etc. | ||
| Working table parameter | |||
| Working table type | Transport conveyor belt | ||
| Conveyor speed | 0-600 mm/s | Conveyor table motor | Servo motor |
| Assistant System | |||
| Protection System | Full protection with optic part structure | ||
| Control System | Perfect Laser professional control card | ||
| Cooling System | Constant temperature water chiller 5kw for laser machine | ||
| Exhaust System | Fixed upper exhaust fans (Filter system is optional) | ||
