| Place of Origin | jiangsu,China |
| Brand Name | Smoothly |
| Certification | ISO9001 |
Professional Corduroy Cutting Machine Fatigue Resistant 9kw Motor Power
Corduroy cutting machine, including a shaft, a plurality of circular knives disposed adjacent each other on the shaft for cutting open floating wefts of a fabric web being movable along a given travel direction, a plurality of needles having points and having longitudinal slots formed therein for receiving portions of the knives defining a cutting edge opposite the knives, a device for inserting the needles into the floating wefts to be cut open in the direction opposite the given travel direction, a contact table disposed below the needle points, a device for stopping the cutting machine upon contact between the contact table and one of the needles, the needles and the contact table defining a working plane for a cutting operation into which the fabric web is guidable from below over the contact table to the cutting edge, a rear table disposed at a distance from the contact table upstream of the needle points in the given travel direction, a device for holding the rear table in the working plane during the cutting operation, a device for lowering the rear table, and the contact table from the working plane, a needle supporting table, and a device for moving the needle supporting table into a region directly below any of the needle points still disposed in the working plane when the rear table is lowered.
| Name | Corduroy Cutting Machine |
| Main Specifications | 210b 200b 180b 180b-350m(Wide New Product) |
| Machinable Fabric Door Width | 2000mm 900m 1700mm To 3500mm |
| Fabric Guide Speed | 12min/M |
| Knife Shaft Speed | 1440rpm/1440rpm/1440rpm |
| Knife Shaft Diameter | 114m |
| The Motor Power | 9kw |
| Machine Exterior (Length*Width*Height) | 2500*3500*2400 |
| Characteristic |
Type B -frequency conversion control ,2~12m/min stepless speed regulation,instantaneous stop,puncture holes and small,save energy. Welcome to guide
|
Product Catalogue
| Machine Type | Cloth Guide Speed | Motor Power | Machine Size |
| Corduroy Cutting Machine | 12m /min | 9kw | 250cm * 235cm * 220cm |
| Textile Singeing Machine | 20 ~ 110m / min | 180KW | 250cm * 235cm * 225cm |
| Textile Dryer Machine | 10 ~ 50m / Min | 10 ~ 22kw | 15000 × 3400 × 3600 (Mm) |
| Fabric Inspection Machine | 1400rpm/min | 7KW | 235cm*350cm*230cm(72") |
| Fabric Inspection Machine | 0-150m/min | 7KW | 250cm * 235cm * 210cm |
| Fabric Inspection And Rolling Machine | ≤100m/min | 1.5kw | 2235(L)*2600~3600(W)*2000(H) |
| Fabric Brushing Machine | 8~22m/min | 14.5-25kw | 250cm * 235cm * 220cm |
| Fabric Folding Machine | 80y/Min | / | 2450*2820*1550 |
FAQ
Q1. Are you trading company or manufacturer?
We are factory. The company is located in Lijia Town, Wujin District, Changzhou City, Jiangsu Province, China.
Q2. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
Q3. Why choose us?
1.Professional Advice and Product Knowledge
2.Prompt Reply for Quotion and other questions
3.Specific Guarantee and Best after service
Q4. Do you inspect the finished products?
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
Q5. What products do you have?
Corduroy Cutting Machine, Textile Singeing Machine,Textile Dryer Machine,Fabric Inspection Machine,Fabric Inspection And Rolling Machine,Fabric Brushing Machine,Fabric Folding Machine, etc.
Q6. What is the order process?
Inquiry - Communication - Quotation - Order confirmation - Payment - Production - Test and commissioning - Packaging - Delivery - Customer reception - After-sales service.
Q7. How about your warranty?
Generally,our warranty is one years. Within the warranty period, we can offer technique support.
Q8. What mode of transportation do you use?
We generally use the mode of sea transportation. If you have any special requirements, you can contact us for discussion.
Q9. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
Q10. Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.
